Carbonation kit 18.9L (quick)

Carbonation Kit 18.9L (Cider, Wine, Cocktail)

The carbonation kit is a complete solution for making and storing carbonated beverages at home. The kit includes everything you need to carbonate cider, wine or cocktails quickly and with professional quality.

General Principle of Use

The carbonation process works as follows: the beverage is poured into a stainless steel pressure vessel, which is connected to a CO2 cylinder via a regulator-reducer. The QuickCarb carbonation device allows carbon dioxide to bind quickly and evenly with the beverage using a combination of a diffusion stone and circulation pump. The result is an evenly carbonated drink in less than an hour.

Kit Contents

Stainless Steel Pressure Vessel (18.9L)

A high-quality stainless steel fermentation and storage vessel manufactured using robotic orbital welding, ensuring smooth weld seams and easy cleaning. The passivated surface provides a matte finish and excellent corrosion protection. Black rubber handles and base make transport easier and protect surfaces from scratches.

Low2 technology ensures longer beverage freshness. High-barrier elastomer O-rings are made from synthetic M-class cross-linked elastomer, providing excellent oxygen barrier properties and preventing oxygen ingress.

• Capacity: 18.9L
• Working pressure limit: 9 bar
• Diameter: 214 mm
• Height: 629 mm
• Warranty: 10 years

The vessel kit includes: Gas and Liquid Ball Lock connections, pressure relief valve (PRV) lid with yellow Low2 O-ring, gas and liquid dip tubes, seals and washers, and beverage label.

Blichmann QuickCarb Carbonation Device

The patented QuickCarb device allows you to carbonate the contents of the pressure vessel in less than an hour. The stainless steel diffusion stone with a 10-micron porous structure ensures efficient and even carbonation. The device operates quietly and reliably.

The carbonation device kit includes: stainless steel diffusion stone, circulation pump, DC transformer and QuickConnector fittings for easy cleaning.

CO2 Cylinder (2L/1.5kg)

A certified carbon dioxide cylinder filled with a minimum pressure of 50 bar. The cylinder is manufactured according to European standard EN 1964:1999 and bears the π marking, confirming compliance with ADR/RID safety requirements.

• Capacity: 2 litres
• CO2 quantity: 1.5 kg
• Dimensions: ø100 x 435 mm
• Weight: 5 kg
• Maximum pressure: 150 bar

CO2 Regulator-Reducer

The regulator-reducer ensures precise and reliable gas pressure control. The device automatically maintains constant pressure and the built-in safety valve ensures safe operation. Two pressure gauges allow monitoring of both cylinder and output line pressure.

• Cylinder connection: W21.8x1 1/4 internal thread
• First gauge: shows CO2 cylinder pressure
• Second gauge: shows output line pressure

Maintenance and Safety

Do not use bleach or chlorine-containing TSP when cleaning stainless steel. Chlorinated trisodium phosphate degrades stainless steel and causes surface damage.
