• SKU: MFP0040

  EAN: 20000000537685

  Filter housing 10" for liquids stainless



  10-inch Industrial Filter Housing for Beverage Filtration - AISI 316 Stainless Steel Professional 10-inch filter housing specially designed for precise filtration of beer, wine, and fruit juices. The device enables efficient cleaning, sterilization, and cold polishing before the bottling process.

  Installation Installation service: we install the device on site according to the manufacturer's instructions, connect to the line (mechanical connections) and perform initial setup and test run. Price depends on location, access and scope of work. (price by agreement / quote)

  No Yes

  Kokkuhoid: 0.00€

  580.00€

  580.00€

  Price without VAT

  467.74€

  467.74€

  To be ordered Delivery time: 21–35 business days

  To be ordered. This product is manufactured to order. The 14-day right of withdrawal does not apply (Law of Obligations Act § 56 (3) 1).

  Add to cart

  Request Quote

  Print
  Availability

  Out of Stock Pärnu

  0 pcs To be ordered

  Delivery

  14-30

  Shipping information

  Loading…
  Warranty 24 months

  To be ordered – right of return does not apply

  B2B invoice payment

  Spare parts from e-shop
• • Description
  • FAQ
  • Specifications

  • Description

    10-inch Industrial Filter Housing for Beverage Filtration - AISI 316 Stainless Steel

    Professional 10-inch filter housing specially designed for precise filtration of beer, wine, and fruit juices. The device enables efficient cleaning, sterilization, and cold polishing before the bottling process.

    Key Features:

    • Made of AISI 316 stainless steel
    • Flow capacity up to 400 l/h
    • Membrane pore size 0.1 - 10 µm
    • Volume: 1.9 liters

    Technical Specifications:

    • Input-output connections: 3/4"
    • Drain connection: 1/4"
    • Vent connection: 1/8"
    • D-type connection
    • Dimensions: 105 x 375 x 318 mm
    • Weight: 3.5 kg

    The filter housing ensures maximum hygiene and effectively removes yeast and bacterial cells while preserving the product's original properties. The device design allows for easy disassembly and cleaning. CE-certified product meets all safety requirements.

    Note! Filter cartridge must be purchased separately.

  • Frequently asked questions about MFP0040

    Which filter cartridges are compatible with this housing?

    The housing accepts standard 10-inch (10") filter cartridges with a Type D (DOE) tip. Depending on the application, a cartridge with a pore size of 0.1-10 µm can be selected — coarser for pre-filtration, finer (0.45 or 0.2 µm) for sterile polishing before bottling.

    Is AISI 316 stainless steel suitable for wine and acidic juices?

    Yes. AISI 316 contains molybdenum, which significantly improves resistance to acids and chlorides compared to AISI 304. It is the industry standard in the production of wine, cider, fruit juice and craft beer where acidic environments come into contact with the equipment.

    How to clean and sterilize the filter housing?

    Disassemble the case, remove the cartridge and rinse all parts with warm water. Use standard CIP procedures with alkaline and acidic cleaners followed by hot-water or steam sterilization. Always use a new or properly regenerated cartridge before sterile filtration.

    What is the maximum throughput and how to measure it?

    The maximum throughput is 400 l/h, but the actual capacity depends on the pore size of the cartridge, the viscosity of the liquid and the number of particles. When sterile filtering beer or wine, operate well below maximum to extend cartridge life and maintain filtration quality.

    Is the filter housing CE certified?

    Yes, the product is CE certified and complies with all applicable EU safety and hygiene requirements for equipment in contact with food. Suitable for commercial breweries, wine estates and juice producers.

  • Specifications

    Length (mm)	105.00
    Width (mm)	375.00
    Height (mm)	318.00
    Weight (kg)	3.50
    Gross Weight (kg)	4.00
    Volume (ml)	2.00
    Unit	pcs
    Throughput	400 L/h
    Filtration accuracy (μm)	10
    Connection size	D
    Certifications	CE
    Voltage	45
    Volume (L)	1.9
    Weight (kg)	3.5kg
