  • Automatic pressurized steam model GVR water tube type
    Automatic pressurized steam model GVR water tube type

  • SKU: 2081

    EAN: 2000005435508

    Automatic pressurized steam model GVR water tube type

    Industrial Steam Boiler EKP-PEL 510 - Powerful Steam Generation System The industrial steam boiler EKP-PEL 510 operating at full capacity ensures stable steam production with an output of 513 kg/h.

    Installation Installation service: we install the device on site according to the manufacturer's instructions, connect to the line (mechanical connections) and perform initial setup and test run. Price depends on location, access and scope of work. (price by agreement / quote)
    No Yes

    119000.00€

    Price without VAT

    95967.74€

    To be ordered Delivery time: 21–35 business days
    To be ordered. This product is manufactured to order. The 14-day right of withdrawal does not apply (Law of Obligations Act § 56 (3) 1).
    Availability
    Out of Stock Pärnu 0 pcs To be ordered
    Shipping information
    Loading…
    Warranty 24 months
    To be ordered – right of return does not apply
    B2B invoice payment
    Spare parts from e-shop

    • Description

      Industrial Steam Boiler EKP-PEL 510 - Powerful Steam Generation System

      The industrial steam boiler EKP-PEL 510 operating at full capacity ensures stable steam production with an output of 513 kg/h. The device is specifically designed to operate at a maximum pressure of 1 bar, offering a reliable solution for industrial steam generation.

      Main Technical Specifications

      • Maximum steam output: 513 kg/h
      • Power capacity: 350 kW
      • Optimal working pressure: 1 bar

      Equipment Configuration

      Main Equipment:

      • EKP-PEL 510 steam boiler
      • Modern pellet burner
      • USKP V-SOTE2 control cabinet for fully automatic operation

      Safety and Control Equipment:

      • Professional steam shut-off valve
      • Condensate return system
      • Precise pressure gauge with control valve and collector
      • Reliable safety valve
      • BCP2 and BCP2H pressure switches
      • High-quality water level indicators (2 sets)

      Water Circulation Components:

      • Energy-efficient Grundfos CM 3-2 pumps (2 pcs)
      • Feed water tank with deaeration zone Z 1000
      • Automatic blow-down system ABV21i DN32
      • Fully automatic desalination system

      Control System Features:

      USKP V-SOTE2 control cabinet ensures:

      • Automatic water level control
      • Flue gas temperature monitoring
      • Optical pump load indication
      • Dry-run protection
      • Short circuit protection

      Warranty and Delivery Information:

      The boiler comes with a 24-month warranty. Additional equipment warranty according to manufacturer terms. Delivery time is approximately 12 weeks from order.

    • Frequently asked questions about 2081

      What fuel does the EKP-PEL 510 boiler use?

      EKP-PEL 510 is equipped with a modern pellet burner designed to work with wood pellets. This enables efficient and renewable fuel use with automated feeding and combustion control via the USKP V-SOTE2 control cabinet, ensuring a stable heat output for steam production of 513 kg/h.

      What is the maximum working pressure and steam output?

      The boiler works at a maximum working pressure of 1 bar and gives a steam output of 513 kg/h at a power of 350 kW. These parameters make it suitable for low pressure applications in industry such as food processing, cleaning and light process heating.

      What safety equipment is included?

      Safety features include a steam shut-off valve, reliable relief valve, BCP2 and BCP2H pressure switches, two water level indicators, dry run protection and short circuit protection. The USKP V-SOTE2 control cabinet also automatically monitors flue gas temperature and water level.

      What is the warranty and delivery time?

      The boiler has a 24-month warranty. Accessories are covered according to each manufacturer's terms and conditions. Estimated delivery time is approximately 12 weeks from order confirmation, including manufacturing, testing and shipping preparation.

      Is the system fully automatic?

      Yes. The USKP V-SOTE2 control cabinet provides fully automatic operation, including water level control, flue gas monitoring, pellet burner control and automatic throttling through the ABV21i DN32 and salt separation system, reducing operator manual operations during normal operation.

    • Specifications

      Length (mm)600.00
      Width (mm)400.00
      Height (mm)400.00
      Weight (kg)22.00
      Gross Weight (kg)141.00
      Unitpcs
      Pressure (bar)1
      Throughput513 kg/h
      Power (W)350000
      Temperature range100°C — 130°C
      Material

      Stainless steel

      Certifications

      CE
